The 1710

7th Gen Manual Programmer

Devices Supported on 7th Gen


The 1710 manual device programmer is manufactured for design engineering and low volume production. It has the versatility to program memories, microcontrollers (MCUs), E/EPROMs, FPGAs, PLDs, and more with any manual or automated socket module, including standard, high-speed FX™, and FX4™ socket modules. FX4™ socket modules are designed specifically for the 7th Generation series of programmers and have the capability of programming four devices simultaneously, enabling users to achieve greater productivity. With existing support for tens of thousands of devices and support for new devices added each day, the 1710 is certain to meet your device programming needs.



  • Programs microcontrollers, memories, E/EPROMs, flash EPROMs, PLDs, CPLDs, FPGAs, antifuse FPGAs, and more
  • Existing support for hundreds of device packages and thousands of socket modules
  • Supports all device packages including, but not limited to, DIP, SDIP, PLCC, TSOP, SSOP, PCMCIA, SOIC, LCC, QFP, PQFP, PGA, SIMM, CSP, BGA, µBGA, TQFP and TSSOP
  • ​Low voltage support down to 1.5V (Vdd)
  • Uses USB 2.0 communication
  • FX4 socket modules include three separate LEDs per socket to indicate device status
  • A patented solution to guard against passing blank parts
  • BPWin provides an intuitive, easy to use interface
  • JobMaster feature for job setup and process control
  • API Option for Job Monitor, Job Control and integration with MES
  • Daily releases for new algorithm additions and updates
  • Optional Lever Socket Actuator
  • No cost lifetime access to BPWin software updates
  • 1-year hardware warranty

1710 Technical Specs

General Specs

Operating Voltage: 100-240 VAC
Frequency: 50-60 Hz
Current Rating: 4-2 A (Fuse 250V 6A SB)
Dimensions: 11.75” (298mm) x 8.65” (220mm) x 4.68” (119mm)
Weight: 7.22 lbs. (3.28 kg)


Required: BPWin
Windows Version: Windows 10, Windows 7 64bit
File Type: including, but not limited to, binary, Intel, JEDEC, Motorola, POF, RAM, straight hex, Tekhex, Extended Tekhex, ASCII hex, Formatted Binary (.DIO), AFM, OMF, LOF
Device Commands: blank, checksum, compare, options, program, test, verify
Features: data editor, revision history, session logging, on-line help, device and algorithm information


Calibration: Annual
Diagnostics: pin continuity test, ROM, CPU, pin drivers, power supply, communications, cable, calibration verification timing, ADC, DAC
PC System Requirements: Windows XP, Windows 7

PIN Drivers

Quantity: 240-pins standard
Analog Slew rate: 0.3 to 25V/µs
VPP Range: 0-25V
IPP Range: 0-70mA continuous, 250mA peak
VCC Range: 0-12V
ICC Range: 0-1A
Very low voltage: to 1.5V (Vdd)
Rise Time: 4ns
Overshoot: none
Clocks: continuously variable 1 MHz to 30 MHz
Protection: overcurrent shutdown, power failure shutdown
Independence: pin drivers and waveform generators are fully independent and concurrent on each site

Standard Accessories Included
  • Software & User manual on a USB thumb drive
  • Power cable
  • Data cable
  • 1-year hardware warranty
  • File Loading: automatic file type identification; no download time because the programmer is PC controlled; supports Intel, JEDEC, Motorola S-record, POF, straight hex, hex-space, Tekhex, and other file formats
  • Device Selection: intelligent device selector allows you to type as little or as much of the part number as you like then choose from a list of devices matching your description
  • Devices Supported: including, but not limited to, Antifuse, Low Voltage, PROM, EPROM, EEPROM, Flash EEPROM, Microcontrollers, SPLD, CPLD, FPGA
  • Continuity Test: each pin, including Vcc, ground, and signal pins, may be tested before every programming operation
  • Protection: overcurrent shutdown; power failure shutdown; ESD protection, reverse insertion, banana jack for ESD wrist straps
  • Options: available Socket Modules including, but not limited to, Universal PLCC, standard PLCC, PGA, CSP, BGA, µBGA, SOIC, QFP, TSOP, LCC, SDIP, PCMCIA, SIMM—JobMaster™ software, and Advanced Feature Software
  • Programming Yield: assured by independent universal pin drivers on each socket, a short distance from pin drivers to device, and accuracy of waveforms
  • Algorithms: all algorithms are manufacturer approved or certified (if required)—BPM Microsystems has an excellent record of being first to provide certified algorithms for new devices
  • Algorithm Updates: software updates are available throughout the year

Complete Ecosystem

BPM Microsystems has ownership of all designs, manufacturing, and support for all programming sites, robotics, vision systems, and software, so we can provide unmatched support and responsiveness

  • Reduce your time to market by doing New Product Introduction/First Article through Automated Production with the same hardware, algorithms, and software
  • 2900 and 2900L for 9th Gen Manual Production and Fast First Articles, plus 2710 and 1710 7th Gen Manual Programmers; the  3901, 28 socket 3928, & 48 socket 4910 for Automated Programming System Productiononly BPM can deliver
